Fiber Laser Metal Cutting 美国十次了
1530
S
- Work area
- Laser power
- Travel speed
- Laser source
- Working area
- 美国十次了 size
- 1500 x 3000 mm
- up to 12 kW
- 100-120 m/min
- Raycus/MAX Photonics/IPG
- 1500х3000 mm
- 2410 x 4610 x 1850 mm
Make a request
Servomotors and gantry work at high speed
Gantry
Servo motors
美国十次了 美国十次了s use a specially designed extruded aluminium gantry. It has high strength characteristics and low weight.
YASKAWA servo motors are reliable, quiet and affordable. They offer high power and low vibration in a compact size.
Several types of frames are available
Frame standard
Frame hard
Manufactured for metal cutters with travel speeds of up to 80 metres per minute. The wall thickness of the frame is 8 to 10 mm. There is a reinforcing rib every 400 mm. The frame is heat-treated to ensure a long service life. 美国十次了 frame warranty is for 8 years. Used in basic models with work field sizes 1010, 1313, 1325 and 1530. Ventilation beam system with holes of different diameters for uniform fume extraction during cutting.
Manufactured for metal cutters with a travel speed of 100 to 160 metres per minute. The wall thickness is 12 to 16 mm. Every 400 mm sheet is reinforced inside the frame. The frame is heat treated to stabilize the metal. Frame has a 10 year warranty. Used in 美国十次了s with working field sizes from 1313 to 2060, used in configurations with an auto-shift or with a pipe cutting module. It has a number of features such as pneumatic flaps for efficient smoke removal during cutting, protection from powerful radiation, preparation for upgrading and others. The frame construction is extremely robust and durable.
美国十次了 metal cutters are designed on feedback from customers and service engineers around the world.
All about the 美国十次了 in 15 seconds
High working speed
Hiwin guide rails/screws are the most reliable and affordable worldwide. High-speed ball screws for fast response of the metal curvature tracking system.
Planetary gears. Nidec-Shimpo withstands high inertia loads with high fail-safe operation.
Advantages of 美国十次了 laser metal cutters
Series comparison
SERIES/
Parameters
Work area
Laser power
Laser head
Motor power Z
Motor power XY
Acceleration
Max. travel speed
Laser source
Cabin
Auto change table
 |
|
| Learn more | Learn more |
| Work area | |
| Laser power | |
| Laser head | |
| Motor power Z | |
| Motor power XY | |
| Acceleration | |
| Max. travel speed | |
| Laser source | |
| Cabin | |
| Auto change table | |
We ensure the smooth running of 美国十次了 美国十次了s
Startup & Training
Service & Support
美国十次了 service engineers help clients and all partners around the world via online or offline training. You can get info on maintenance, basic 美国十次了 operations, tips for processing various materials, etc. We launch and train more than 100 clients monthly.
Our service team operates across the world, and 美国十次了 美国十次了s are presented even in Antarctica. We offer an offline and online support system for clients, and it will be available for you throughout the whole 美国十次了’s lifespan.
All of our equipment comes with a warranty and a guaranteed return policy.
All of our equipment comes with a warranty and a guaranteed return policy.
Materials
The 美国十次了 can process
Aluminum
Carbon steel
Stainless steel
Brass
Copper
Galvanized steel
Titanium
Technical
characteristics
Dimensions
Working area
1500х3000 mm
美国十次了 size
2410 x 4610 x 1850 mm
Packing size
5300 х 2200 х 1800 mm
Net Weight
2200 kg
Optics
Laser head
Raytools/Precitec/BOCI
Laser power
up to 12 kW
Mechanics
Motors
Yaskawa
Engine power Z
400 W
Engine power XY
850 W/1300 W*2
Gearboxes
NIDEC-SHIMPO
Structure of the axes XY
Guides HIWIN/Helical rack LEAN/Leitesen
Structure of the axes Z
HIWIN Guides/Ball Screws
Height sensor
Automatic capacitive
Lubrication system
Automatic centralised, 美国十次拉
Max. travel speed
100-120 m/min
Max. operating speed
Depends on the material
Additional gas
Oxygen, nitrogen, air, argon
Auto change table
No
Bed
Control system
FSCUT
Power electrics
Siemens
Repositioning accuracy
±0.03 mm
Height control system
BCS100
Type of end sensors
Inductive
Working temperature
10-40 °C
Laser source
Raycus/MAX Photonics/IPG
Laser power adjustment
10-100 %
Software
FSCUT
FSCUT
Laser head
RAYTOOLS
RAYTOOLS
Laser source
IPG
IPG
Motors
MITSUBISHI
MITSUBISHI
HIWIN
Make a request
Logistics
We will deliver the equipment under the most convenient conditions for you
If the 美国十次了 is not in stock when you purchase it, you must first wait for the assembly process to be completed. It can take at least three weeks (and up to six months). The delivery time itself ranges from 0 days to a month.
We may deliver on various terms. The most popular ones are EXW, FOB, CIF, and DDP. You can have a 美国十次了 delivered to your workplace, the destination port, or you can organise the delivery yourself by contacting logistics providers.
EXW is the most basic shipment type, FOB and CIF may be considered the golden mean, and DDP is the most convenient.
Technical
characteristics
Dimensions
Working area
1500х3000 mm
美国十次了 size
2410 x 4610 x 1850 mm
Packing size
5300 х 2200 х 1800 mm
Net Weight
2200 kg
Optics
Laser head
Raytools/Precitec/BOCI
Laser power
up to 12 kW
Mechanics
Motors
Yaskawa
Engine power Z
400 W
Engine power XY
850 W/1300 W*2
Gearboxes
NIDEC-SHIMPO
Structure of the axes XY
Guides HIWIN/Helical rack LEAN/Leitesen
Structure of the axes Z
HIWIN Guides/Ball Screws
Height sensor
Automatic capacitive
Lubrication system
Automatic centralised, 美国十次拉
Max. travel speed
100-120 m/min
Max. operating speed
Depends on the material
Additional gas
Oxygen, nitrogen, air, argon
Auto change table
No
Bed
Control system
FSCUT
Power electrics
Siemens
Repositioning accuracy
±0.03 mm
Height control system
BCS100
Type of end sensors
Inductive
Working temperature
10-40 °C
Laser source
Raycus/MAX Photonics/IPG
Laser power adjustment
10-100 %
Software
FSCUT
FSCUT
Laser head
RAYTOOLS
RAYTOOLS
Laser source
IPG
IPG
MITSUBISHI
Rails
HIWIN
HIWIN
